Heavy-Duty Apron Feeder Manufacturer

Heavy-Duty Apron Feeder

Apron Feeder: Light-Duty Apron Feeder, Medium-Duty Apron Feeder, Heavy-Duty Apron Feeder

Apron Feeder
Apron Feeder

WBZ series heavy-duty apron feeders can be used to convey various lumpy or loose materials from storage to crushers, conveyors or other working machinery along the horizontal or inclined direction. Heavy-duty apron feeders are indispensable equipment in raw material processing or continuous production, and are widely used in building materials, metallurgy, mining and other industries.

What is Heavy-Duty Apron Feeder?

A heavy-duty apron feeder is specifically designed for handling extremely heavy and abrasive bulk materials in industrial and mining applications. It consists of a series of overlapping pans or plates that are typically made of high-strength steel or other wear-resistant materials, and they are connected to heavy-duty chains or rollers.

The pans or plates of a heavy-duty apron feeder are typically deeper and wider than those of standard apron feeders, allowing for a larger capacity and more effective handling of heavy and bulky materials. The feeder is also engineered with a robust design and heavy-duty components, such as large rollers or sprockets, which can withstand the extreme impact and abrasive forces associated with heavy mining and industrial operations.

Heavy-duty apron feeders have many advantages, including high reliability, low maintenance, and long service life. They are capable of handling a wide range of materials, including ores, coal, aggregates, and heavy-duty construction wastes. Heavy-duty apron feeders are also used in extreme operating environments, such as hot temperatures or corrosive atmospheres, where standard feeders would be unable to perform.

Read More: Apron Feeders, Everything You Need to Know, Best Guide 2023

Top 6 characteristics of WBZ heavy-duty apron feeder

  • The heavy-duty apron feeder adopts YVF2 series frequency conversion speed-regulating motor and planetary gear reducer to directly reduce the transmission, which simplifies the structure and improves the transmission efficiency.
    The feeding volume can be adjusted smoothly through the frequency conversion speed regulating device. The power configuration and constant torque output adapt to the working conditions of load start-up and incoming materials changeable, so that the supporting equipment can receive materials evenly and work stably, which is conducive to the realization of system automation. A wide range of needs to meet different production volume requirements.
  • The main shaft, the bearing and the sprocket are all connected by expansion sleeves and withdrawal sleeves, which can avoid the stress caused by keyway opening and facilitate assembly, disassembly and maintenance.
  • The driving sprocket adopts the detachable bulldozer special drive wheel tooth block, and the chain adopts the special crawler chain of bulldozer, which is safe and reliable in operation, easy to use, and the chain does not need to be frequently oiled. It adopts a new conveying trough design, which has good rigidity, impact resistance, good airtight performance, and no leakage, scattering, deviation, etc.
  • The supporting structure of the chain and the channel plate adopts the roller support structure combined with supporting wheels and supporting wheels, which has high rigidity, impact resistance and small running resistance. The material receiving section is equipped with a buffer device, which can slow down the impact of the material on the channel plate and extend the channel plate. Service life; improve the service life of the whole machine.
  • The tail tensioning device is equipped with a spring device and a sliding bearing seat, which can slow down the impact load of the chain and prolong the service life of the chain. At the same time, the discharge port is equipped with dense rollers, which can reduce the impact of materials on the channel plate and prolong the service life of the channel plate.
  • According to the actual situation of the site, it can be used to land horizontally or with large feet to reduce civil construction, and the maximum inclination angle can reach 23°.
Apron Feeder
Apron Feeder
Apron Feeder
Apron Feeder
Apron Feeder
Apron Feeder

8 Safety measures for the use of heavy-duty apron feeders

  • Inspection, maintenance and overhaul can only be carried out after the crushing and feeding system is completely closed, and accidental startup must be avoided;
  • Turn off the main switch (and service switch) and remove the key.
  • Warning sign on main switch disposal.
  • If the safety device needs to be disassembled during maintenance and inspection, after the repair is completed, it should be reinstalled and its function tested!
  • Mechanical parts and large assemblies should be carefully secured to lifting gear during heavy-duty apron feeder servicing to avoid hazards. Sufficient and technically fault-free lifting gear and shipping equipment should be used.
  • When assembling or overhauling equipment at a place higher than the human body, standard escalators or other safety ladders or working platforms must be used.
  • Keep all handles, steps, handrails, landings, working platforms and ladders free of dirt, snow and ice!
  • Use fall protection when working at heights!

Read More: Variable rate feeder wikipedia

Technical parameter of heavy-duty apron feeders

ModelChain plate
Width		Chain wheel
center distance
mm		Chain plate
Speed
m/s		Feed size
mm		Capacity
m3/h		Motor
Model		Motor
Power(KW)		L × W× H
(mm)		Weight
(kg)
WBZ120-4.5120045000.05≤500100Y160L-4156983×5228×208031279
WBZ120-5120050000.05≤500100Y160L-4157593×5228×208033427
WBZ120-5.6120056000.05≤500100Y160L-4158183×5228×208034321
WBZ120-6120060000.05≤500100Y160L-4158638×5228×208035900
WBZ120-8120080000.05≤500100Y180L-42210533×5293×208041342
WBZ120-8.7120087000.05≤500100Y180L-42211383×5293×208043164
WBZ120 101200100000.05≤500100Y180L-42212583×5293×208046962
WBZ120-121200120000.05≤500100Y180L-42214653×5293×208051844
WBZ120-151200150000.05≤500100Y200L-43017658×5518×208062157
WBZ150-4150040000.05≤ 600150Y160L-4156613×5528×208033197
WBZ150-6150060000.05≤ 600150Y180L-4228638×5593×208039257
WBZ150-7150070000.05≤ 600150Y180L-4229633×5593×208043352
WBZ150-8150080000.05≤ 600150Y180L-42210533×5593×208045962
WBZ150-9150090000.05≤ 600150Y200L-43011683×5668×208050522
WBZ150-121500120000.05≤ 600150Y225M-44514653×5888×208059915
WBZ180-6180060000.05≤800240Y225M-4458651×6463×208046840
WBZ180-8180080000.05≤800240Y225M-44510533×6188×208051360
WBZ180-9.5180095000.05≤800240Y225M-44512033×6183×208057397
WBZ180-101800100000.05≤800240Y225M-44512593×6188×208059632
WBZ180-121800120000.05≤800240Y225M-44514653×6363.5×208066029
WBZ240-4240040000.05≤1000400Y200L-4306613×6718×208044780
WBZ240-5240050000.05≤1000400Y200L-4307533×6718×208050737
WBZ240-5.6240056000.05≤1000400Y200L-4308133×6718×208052447
WBZ240-102400100000.05≤1000400Y225M-44512593×6718×208076373
WBZ240-122400120000.05≤1000400Y225M-44514653×6718×208085331
